Product Name: 2 mm flux cored aluminum soldering wire
Material: 50% Tin and 50% Lead
Diameter: 2.0mm
OEM: Available
Free Sample: Available
Supply Ability: 6 Ton/Tons per Week
Payment Terms: T/T, L/C, PayPal, West Union
Product name | 2 mm flux cored aluminum soldering wire |
Material | 50% Tin and 50% Lead |
Diameter | 2.0mm |
Melting Point | 183℃-216℃ |
Weight | 1000g/reel |
Flux Content | 1.8-2.4% |
Shape | Wire |
Color | Silver grey |
1. Composition: Tin and Lead
2. Diameter of solder wire: From 0.5mm to 5.0mm are available.
3. Dimension of solder bar: 28.5cm * 1.8cm * 1.3cm, around 500grams/pc.
4. Melting temperature and Working temperature for the solder bar:
Alloy Composition (wt%) | Melting Temperature ℃ | Working Temperature ℃ | Working Method |
Sn63/Pb37 | 183 | 245-255 | Wave Soldering |
Sn60/Pb40 | 183~190 | 250-260 | Hot-Dip Soldering |
Sn55/Pb45 | 183~203 | 255-270 | Hot-Dip Soldering |
Sn50/Pb50 | 183~216 | 260-275 | Hot-Dip Soldering |
Sn45/Pb55 | 183~227 | 270-300 | Hot-Dip Soldering |
Sn40/Pb60 | 183~238 | 280-310 | Hot-Dip Soldering |
Sn35/Pb65 | 183~247 | 290-330 | Hot-Dip Soldering |
Sn30/Pb70 | 183~255 | 295-335 | Hot-Dip Soldering |
Sn25/Pb75 | 183~266 | 300-350 | Hot-Dip Soldering |
Sn20/Pb80 | 183~280 | above 350 | Hot-Dip Soldering |
5. Features:
a) Smokeless, Little splash, Bright and Stable spot.
b) No corrosion, high insulation resistance and no-clean.
c) Little residues, Good wettability and excellent oxidation resistance.
d) Quick melting speed and good fluidity
6. Aluminum solder wire Specification:
Item | 2 mm flux cored aluminum soldering wire | ||||||||
Flux content (%) | 1.8-2.4% | ||||||||
Specific gravity | 7.3 | ||||||||
Melting point | 183-216℃ | ||||||||
Usage | Suitable for use with standard wave soldering/solder posts | ||||||||
Storage information and warrantee period | Store in a cool, dry, non-corrosive environment. Product warrantee period of 2 years | ||||||||
Chemical composition of solder alloy |
|
|
|
|
|
|
| ||
Metal element | Sn | Pb |
|
|
|
|
|
|
|
Composition (%) | Balanced | 49.9 |
|
|
|
|
|
|
|
Maximum threshold of impurities in solder alloy |
|
|
|
|
|
|
| ||
Metal element | Bi | Zn | Fe | Al | As | Cd | Cu | Sb | |
Composition (%) | 0.027 | 0.002 | 0.007 | 0.007 | 0.03 | 0.002 | 0.04 | 0.12 | |
Notes: This product and all components are compliant with GB/T 3131-2001 | |||||||||
2 mm flux cored aluminum soldering wire application：
Widely used in LED, PCB, Precise Instruments and Electronic components and so on
Aluminum solder wire Packaging:
1. Weight is reel: 100g, 125g, 250g, 1LB, 500g, 900g, 1kg/reel are available.
Package for 100g and 125g/reel solder wire: 100 reels/box, 2 boxes /carton
Package for 250g/reel solder wire: 40 reels/box, 2 boxes /carton
Package for 1LB and 500g/reel solder wire: 20 reels/box, 2 or 4 boxes/carton
Package for 900g and 1kg/reel solder wire: 10 reels/box, 2 or 4 boxes/carton
2. Weight in tube: 12g, 15g, 17g and 20g/tube are available.
Package: 500pcs or 600pcs/carton
Shipping:
1. Samples are shipped by Express or by air.
2. Orders are shipped by sea or by air.
Our Services
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customize is available, OEM&ODM are welcome.
FAQ
1. What is your advantage?
Manufacturer Better price, Good quality and reputation, Best service for sales
2. Can you offer the free sample for testing?
Yes, we can offer free sample for testing, but the freight cost should be paid by customer side.
