Tin Lead Resin Flux Solder Wire

Product Name: tin lead resin flux solder wire
Material: Tin and Lead
Diameter: 0.8-3.0mm
OEM: Available
Free Sample: Available
Supply Ability: 6 Ton/Tons per Week
Payment Terms: T/T, L/C, PayPal, West Union

Send Inquiry

Product Details

Product name

tin lead resin flux solder wire

Material

Tin and Lead

Diameter

0.8-3.0mm

Melting Point

183℃-280℃

Weight

50-1000g/reel

Flux Content

1.8-2.4%

Shape

Wire

Color

Silver grey

Flux core

Resin flux

Composition

Tin and Lead

Working tools

Soldering irons


1. Composition: Tin and Lead
2. Diameter: From 0.5mm to 3.0mm are available.
3. Melting temperature and Working temperature:

Alloy Composition (wt%)

Melting Temperature ℃

Working Temperature ℃

Working Method

Sn63/Pb37

183

245-255

Wave Soldering

Sn60/Pb40

183~190

250-260

Hot-Dip Soldering

Sn55/Pb45

183~203

255-270

Hot-Dip Soldering

Sn50/Pb50

183~216

260-275

Hot-Dip Soldering

Sn45/Pb55

183~227

270-300

Hot-Dip Soldering

Sn40/Pb60

183~238

280-310

Hot-Dip Soldering

Sn35/Pb65

183~247

290-330

Hot-Dip Soldering

Sn30/Pb70

183~255

295-335

Hot-Dip Soldering

Sn25/Pb75

183~266

300-350

Hot-Dip Soldering

Sn20/Pb80

183~280

above 350

Hot-Dip Soldering

4. Features:   a) Smokeless, Little splash, Bright and Stable spot.
b) No corrosion, high insulation resistance and no clean.
c) Good wettability and excellent oxidation resistance.
d) Quick melting speed and good fluidity.
5. Specification ---- Tin solder wire

Item

tin lead resin flux solder wire

Flux content (%)

1.8-2.4%

Specific gravity

8.3-10.1

Melting point

183-280℃

Usage

Suitable for use with soldering irons and soldering irons

Storage information and warrantee period

Store in a cool, dry, non-corrosive environment. Product warrantee period of 1 years

Chemical composition of solder alloy















Metal element

Sn

Pb















Composition (%)

Balanced

As request















Maximum threshold of impurities in solder alloy















Metal element

Bi

Zn

Fe

Al

As

Cd

Cu

Sb

Composition (%)

0.027

0.002

0.007

0.007

0.03

0.002

0.04

0.12

Notes: This product and all components are compliant with GB/T 3131-2001


tin lead resin flux solder wire application

Used by soldering irons in manual soldering and automated machine.
Sn63 and Sn60 solder wires are general used in Lighting, LED, PCB, Precise instruments, Electronic components, Audio and sound system and so on.
Sn55 and Sn50 solder wires are general used in Mechanical, Toys, Electrical, Socket and so on.
Sn45, Sn40, Sn35, Sn30, Sn25 and Sn20 solder wires are general used in Lamp holder, Battery, Fuse, Radiators, Automobile parts and other general soldering.

Packing:

1. Packed with wooden case
2. Cardboard case
3. According to clients ' demand

Shipment type:

By Courier, by air or by sea
